Track-mounted SPT Soil Test Drilling Machine | SPT Rig

Choosing a soil test drilling machine is the most critical decision for modern industrial contractors. It determines site investigation accuracy, reduces project overhead, and ensures structural safety before foundation design. Today, global infrastructure demands flawless geological data. Inaccurate sampling leads to structural failure and causes massive financial liabilities.

YG Machinery engineered its high-precision product line to solve these borehole challenges. This technology marks a major leap forward for the site investigation sector. Our machines feature an automated dual-cooling system and heavy-duty hydraulic components. They guarantee exact core extraction and reduce reliance on inefficient legacy equipment. Industry data confirms the impact. Automated hydraulic platforms can triple sampling speed and minimize operational downtime. This makes our equipment an essential asset for any serious engineering fleet—helping you scale operations and win high-tier commercial contracts.

4 Crucial Features to Evaluate in Your Next SPT Drill Rig

Investing in a premium rig transforms your site investigation capabilities. It provides unparalleled depth capacity. It ensures high soil sampling precision on every project. This robust equipment uses advanced hydraulic systems. They deliver stable rotation torque. They provide high lifting force. This power helps handle difficult geological formations.

• Dual-Cooling Efficiency: It combines air cooling and water cooling mechanisms. It maintains optimal hydraulic fluid temperature.
• Massive Structural Power: It utilizes reliable diesel engines. Yuchai and Cummins brands generate up to 154kW.
• Flexible Angular Drilling: It adjusts between 0 and 90 degrees. This allows versatile angle borings for retaining walls.
• Integrated Fluid Management: It incorporates a high-pressure mud pump. It delivers up to 180 liters per minute.

By integrating this equipment, survey teams secure large-scale infrastructure projects. These jobs demand strict compliance with international standards. The return on investment becomes clear quickly. Fuel efficiency improves. Mechanical breakdown rates drop significantly across varied terrains.

Technical Specifications of SPT Soil Test Drilling Machine

Model	YGX-400	YGX-600	YGX-800	YGX-1000
Drilling Depth (M)	180-400-500	200-600-650	400-800-1000	500-1000-1100
Rated Pressure (MPa)	21	21	25	28
Rated Flow (L/min)	168	192	260	300
Heat Dissipation Mode	Air + water cooling	Air + water cooling	Air + water cooling	Air + water cooling
Engine Brand	Yuchai	Yuchai	Yuchai	Cummins
Rated Power / Speed	78kW / 2400rpm	92kW / 2400rpm	92kW / 2400rpm	154kW / 2400rpm
Drilling Angle (°)	0-90	45-90	45-90	45-90
Lifting Force (T)	12	16	24	30
Feed Force (T)	6	8	12	15
Hydraulic Mud Pump Flow	30-90 L/min	30-90 L/min	90-180 L/min	90-180 L/min
Hydraulic Mud Pump Power	4-7 MPa	4-7 MPa	4-7 MPa	4-7 MPa
Dimension	4000x1900x1800mm	4000x2000x1800mm	5500x2100x2000mm	6000x2200x2400mm
Weight	4.3T	4.5 / 5.5T	6.5T	7.5T

Why a Heavy-Duty Geotech Drill Rig Guarantees Maximum Core Recovery

Deploying a high-capacity apparatus guarantees excellent results. Field technicians extract undisturbed soil profiles easily. They can drill through dense gravel beds. They penetrate hard bedrock layers smoothly. The equipment functions by utilizing synchronized hydraulic pressure controls. They dynamically match the rotational speed. This speed adapts to subsurface resistance.

• Optimized Pressure Distribution: The integrated system delivers up to 28MPa. This allows smooth penetration through compacted glacial till.
• High-Volume Flushing Capacity: The mud pump provides up to 7MPa power. It ensures complete borehole stabilization.
• High-Tonnage Extraction Power: Operators handle massive steel casing strings easily. Premium hydraulic winches provide 30 tons of force.
• Rugged Steel Track Construction: It effortlessly navigates remote job sites. It works perfectly in swampy or mountainous areas.

This intelligent mechanism ensures uniform downward pressure. It eliminates sample distortion. It stops erratic mechanical jumping. Therefore, laboratory engineers receive pristine cores. These samples accurately reflect true in-situ density. This drastically reduces the need for costly redrills.

Maximizing Uptime with Your New Soil Test Drilling Machine

The internal engineering focuses heavily on component longevity. It prioritizes structural balance. It ensures ease of maintenance in extreme environments. A combined air and water cooling system protects the parts. The machinery operates continuously in high ambient temperatures. The hydraulic oil does not thin out. Furthermore, genuine industrial diesel engines ensure steady power delivery. Heavy-duty main pumps support critical testing phases. The high-capacity rated flow prevents torque drop-offs. It ensures steady bit rotation across varying subsurface profiles. This optimized mechanical harmony reduces component failures. Operations managers experience significantly lower long-term maintenance costs.

Additionally, the centralized hydraulic console provides exceptional visibility. The operator monitors the borehole line easily. They watch the mast assembly during critical hoisting maneuvers. The technician adjusts feed force smoothly. They control rotation speed via responsive valves. This maintains ideal bit weight in sensitive clay layers. This granular level of control ensures steady drilling. It provides an exceptionally stable platform. The unit is immediately ready for precise split-spoon sampling. It handles thin-walled Shelby tube insertions perfectly.

Mechanical Safety Metrics for a Soil Test Drilling Machine

Beyond pure boring speeds, structural robustness dictates profitability. Your commercial contracting business relies on durable equipment. Each component undergoes intense stress simulation. This ensures they withstand immense torsional forces. The machinery easily handles thousand-meter deep holes. The reinforced steel mast frame resists bending. It keeps the borehole path perfectly straight. It maintains accuracy over extended depths. Engineers choose world-class internal components. High-torque hydraulic motors provide reliable power. Heavy-duty track assemblies maintain stable positioning. The machine eliminates dangerous mast shifting on site. This prevents severe accidents. It protects expensive drill strings from damage.

Furthermore, balanced weight distribution prevents excessive ground pressure. The wide crawler chassis protects soft, uncompacted soils. It prevents sinking in alluvial mudflats. Contractors confidently deploy these units on challenging projects. They work well for urban highway expansions. They excel in high-altitude mining investigations. The platform holds its ground securely. This versatile design allows quick method swapping. Operators switch between conventional mud rotary drilling and continuous flight augering. They can use advanced diamond coring techniques. This maximizes fleet utilization rates across diverse global geology.

Choosing the Best SPT Testing Drill Rig Configuration

Finding the right system requires careful analysis. Contractors evaluate specific parameters like maximum depth requirements. They check targeted soil conditions. They consider transportation weight constraints. YG Machinery offers customized configurations. These suit shallow urban environmental testing. They also handle massive, thousand-meter-deep geological exploration.

• YGX-400 (Compact Versatility): This highly agile, 4.3-ton unit features a 78kW engine. It offers a full 0-90 degree range.
• YGX-600 & YGX-800 (Mid-Range Powerhouses): Driven by powerful 92kW engines, these models provide 24 tons of lifting force.
• YGX-1000 (The Deep-Hole Flagship): Weighing 7.5 tons, this model packs a 154kW Cummins engine. It delivers 30 tons of force.

Selecting the appropriate technical specification optimizes diesel fuel consumption. It maximizes daily production rates. It aligns fleet capabilities with project requirements. Our extensive global logistics framework ensures safe delivery. Every machinery acquisition comes backed by reliable technical assistance. Replacement parts are readily available. We provide thorough field operation training guides. Contact the engineering consultation group at YG Machinery today. Request a comprehensive pricing structure. Evaluate shipping arrangements. Receive expert product recommendations for your upcoming geotech exploration initiatives.

Secure Your Wholesale Direct Factory Quote for Our Soil Test Drilling Machine Today

Buying equipment directly from an established global heavy machinery manufacturer eliminates expensive third-party broker markups. YG Machinery provides worldwide commercial buyers with comprehensive international equipment warranties. We ensure rapid spare parts fulfillment. We offer lifetime technical engineering support. Our application engineering division is ready to review your project requirements. We calculate the ideal machine combinations. We configure custom mast frames for your specific regional geology.

• Step 1: Submit your preferred depth capacity and target soil types through our simple online inquiry form.
• Step 2: Review an itemized, transparent PDF quotation and exact machinery weights within 24 hours.
• Step 3: Confirm your customized equipment specifications and monitor your shipment from our manufacturing floor directly to your port.
